What is Activated Carbon

In the world of chemical engineering and refining industries, Activated Carbon (AC) is recognized as one of the most complex yet efficient adsorbent materials. Derived from the pyrolysis of carbonaceous materials, it features a structure where carbon atoms are arranged to create maximum microscopic void space. This internal porosity grants activated carbon an incredible surface area for physical and chemical reactions; so much so that a single handful of this black powder can cover an area equivalent to several hectares. In this article, we take a detailed look at the production nuances, various types, and extensive applications of this material in key industries.



Specialized Production Methods of Activated Carbon

Activated carbon is a solid, porous material whose primary difference from ordinary charcoal lies in its extremely high specific surface area, which sometimes exceeds 1000 m²/g.

Physical (Thermal) Activation Method

In the physical activation method, the raw material is first carbonized at high temperatures in an environment completely isolated from oxygen to form the initial charcoal structure. Subsequently, the resulting char is exposed to oxidizing gases such as steam or carbon dioxide at temperatures between 800°C and 1100°C. This process opens blocked pores and maximizes adsorption capacity. Due to the absence of corrosive chemicals, this method is highly favored for producing high-purity carbons used in sensitive industries like drinking water treatment, yielding a product with high mechanical strength.



Chemical Activation Method

Chemical activation is typically used for wood-based or lignocellulosic raw materials. In this process, the raw material is impregnated with powerful dehydrating agents such as phosphoric acid or zinc chloride before heat treatment. These chemicals act as dehydrating agents, causing the carbon structure to open at lower temperatures (around 400°C to 700°C) and creating larger pores (macropores). The main advantage of this method is the precise control over pore size and higher production yield compared to the physical method, although thorough final washing to remove chemical residues is a priority.

Classification of Activated Carbon by Morphology

Activated carbon is categorized into different classes based on particle size and production method, each serving specific applications:

Granular Activated Carbon (GAC)

GAC consists of relatively coarse particles (usually above 0.8 mm). Due to its high diffusion rate and low pressure drop, it is the preferred choice for continuous water and gas flow treatment. Its robust structure allows for thermal reactivation and multiple reuses, making it highly cost-effective for large-scale treatment plants. The optimal contact surface and physical stability of granules ensure high-efficiency removal of organic pollutants and chlorine in fixed-bed filtration systems.

Powdered Activated Carbon (PAC)

PAC comprises extremely fine particles, typically less than 0.15 mm in size. Due to its vast surface area-to-volume ratio, it offers exceptionally high adsorption rates in rapid reactions. This type is added directly to reaction tanks and subsequently removed via sedimentation or filtration. Its primary use is in municipal wastewater treatment for seasonal taste and odor control, as well as in the pharmaceutical industry for raw material purification, where short contact time and instantaneous adsorption are critical.

Extruded or Pelleted Activated Carbon (EAC)

Produced through extrusion, EAC has a regular cylindrical shape designed mainly for gas-phase applications and air filtration. The specific geometric shape and the void spaces between pellets minimize pressure drop against airflows, making it ideal for gas masks, automotive filters, and solvent recovery units. The high hardness of these pellets prevents attrition and dust formation caused by gas flow friction, significantly increasing the service life of industrial ventilation systems.

Raw Materials and Their Characteristics

Coconut Shell-Based Activated Carbon

This is the most popular and highest-quality type of activated carbon globally. Due to its high density of micropores, it possesses an unparalleled ability to adsorb very small molecules. It features extreme hardness, preventing ash and dust production in water treatment systems. Being 100% natural, it is the safest option for food and grade applications. Its high density and low attrition rate have made it the "gold standard" in home water purifiers and gold recovery industries.



Coal-Based Activated Carbon (Anthracite)

Coal-based carbons possess a broad spectrum of pore sizes (micro, meso, and macropores), making them versatile adsorbents for diverse pollutants. Due to cost-effectiveness and raw material availability, they are widely used in large industrial and municipal wastewater plants. This diverse pore structure allows for the simultaneous removal of small toxic molecules and larger color bodies, though its ash content is slightly higher than plant-based alternatives.

Strategic Industrial Applications

Food and Sugar Processing Industry

In the food industry, activated carbon acts as a purifier and polishing agent. Its primary role is removing undesirable pigments and off-flavor compounds from edible syrups and liquid sugar. As sugar solutions pass through carbon beds, colloidal impurities causing turbidity are adsorbed, resulting in a crystal-clear final product. Additionally, in edible oil production, specific PAC grades are used to remove pesticide residues and aromatic compounds.



Gold and Precious Metal Extraction

In the mining industry, GAC is used via the "Carbon-in-Pulp" (CIP) method to recover gold from cyanide leach solutions. Due to its high affinity for gold-cyanide complexes, AC concentrates the gold within its pores for subsequent elution. Carbon quality is vital here; any fragmentation in stirred tanks leads to gold loss, hence why the hardest coconut shell carbons are utilized.

Pharmaceutical and Medical Applications

Medically, activated carbon is known as a universal antidote, administered orally in acute poisoning cases to bind toxins in the gastrointestinal tract before they enter the bloodstream. Its massive surface area is highly effective in adsorbing drugs like aspirin, acetaminophen, and certain narcotics. In labs, it is also used to decolorize antibiotics and separate unwanted by-products during drug synthesis.



Technical Parameters and Quality Standards

Iodine Number and Its Significance

The Iodine Number is a key technical indicator of adsorption capacity, representing the micro-pore volume. Measured in mg of iodine adsorbed per gram of carbon, it correlates directly with the active surface area. High-quality carbons usually range between 800 to 1100 mg/g. A higher iodine number signifies greater power in removing small contaminants like chlorine and Volatile Organic Compounds (VOCs).



Hardness and Attrition Resistance

In applications involving high-pressure water flow or mobile beds, hardness is crucial as it indicates resistance to crushing and dusting. Low-hardness carbons degrade quickly, clogging nozzles and causing turbidity. Coconut-based carbons naturally possess the highest hardness, making them ideal for backwashing systems and continuous industrial handling.



Competitive and Economic Advantages

Microscopic Pollutant Removal Efficiency: AC removes contaminants invisible to the naked eye (like pesticides and drug residues) using Van der Waals forces.

Environmental Compatibility: Derived from renewable sources (coconut shells, wood), it reduces the industrial carbon footprint.

Long-term Operational Cost Reduction: High adsorption capacity leads to longer filter life and less downtime.

Customizability: Pore sizes can be engineered for specific target molecules.

Operational Simplicity: Unlike Reverse Osmosis (RO), carbon filters are easy to operate and require no complex energy-intensive equipment.



Maintenance and Thermal Reactivation

After prolonged use, activated carbon becomes "spent" or saturated. Through thermal reactivation in rotary kilns at 800°C, adsorbed pollutants are burned off, reopening the pores without destroying the carbon itself. This recycling capability allows large industries to reduce operational costs by up to 50%.
